Inconel 600/601/625 Sheets Plates and Coil, Inconel 601 Cold Rolled Coils, Inconel Alloy N06601 Coils, ASTM B168 Inconel HR Sheets and Plate Manufacturer, NCF 600 Sheets, UNS N06600 Plate, Inconel Industrial Sheets, Plates and Coils Supplier in Mumbai India.
Inconel Alloy 2.4856 Slit Coils, Inconel Alloy N06625 Perforated Sheets, Inconel 2.4668 Shim Sheets, Incoloy 600/601/625 Strips Plates and Coil, ASME SB168 Alloy 601 Sheets Stockist, Inconel N07718 Chequered Plate, Alloy 600, 601, 625 Sheets, Plates, Coils Exporter in India.
Stanleyalloys is a wide range of suppliers and manufacturers of Inconel 600/601/625 Sheet plate coil. The large-scale collection of alloys offers excellent properties such as high tensile strength, non-breakable, malleable, longer life, tested and assured proof collection. Inconel 600 Sheets and Plates is a nickel-chromium incorporated alloy used for an application that demands high-temperature resistance and corrosion. Inconel unjointed 601 Sheets and Plates is a nickel-chromium incorporated alloy used for an application that requires resistance to corrosion and heat, utilizing aluminum adding up for superior resistance to oxidation and other types of raised temperature resistance. Inconel 625 Sheets and Plates is nothing but corrosion, non-magnetic and oxidation resistant nickel alloy, which is applied to both its high strength and excellent aqueous corrosion resistance
Grades:
For Case, Inconel 625 has a nickel content ranging from 58-59% as a minimum which means it falls among the middle of 330 and 600 alloys. Whereas alloy 600 has nickel content ranges 71-72% as a minimum. On the other hand, Inconel 601 consists of 58-63% nickel.
Specification of Inconel 600, 601, 625 Sheets, Plates, Coils
Specifications : ASTM B168 / ASME SB168, AMS 5540
Dimensions : ASTM, ASME, and API
Inconel Sheet : thickness range from .008" to .0125"
Inconel Plate : thickness ranges from .0125" to 5.00"
Size : 15NB to 150NB In
Tempers : Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Applications:
These Inconel alloys are widely recognized for their resistance from corrosion in high temperature and aqueous or low temperature. Each alloy has its distinct advantages, and each is used in multiple industries. For a case, Inconel 601 and 600 have both efficient roles in the chemical and food processing industries. Whereas Inconel 625 differs from other alloys as it consists of sufficient nickel, molybdenum, and chromium, as they are effective in splitting corrosion, they have been chosen for making materials in aerospace and marine engineering industries.
With nickel-chromium alloy, Inconel 601 increases its resistance from oxidation and various forms of corrosion, which made Inconel 601 a common material in heat treating equipment, gas turbines and furnaces components. At the same time, the ability to withstand corrosion in a different form has made Inconel 600 a perfect alloy to prefer in the food industry and nuclear engineering because it will maintain its structure and help permanently for distorting different alloys. On the other hand, Inconel 625 is also used for heat shields, furnace hardware, combustion liners and spray bars, etc.
Available Types of Inconel Alloy 600, 601, 625 Sheets and Plates, Coils
Alloy 600, 601, 625Sheets
Inconel 600, 601, 625 Sheets
Inconel 600 Cold Rolled Sheets, Alloy 601 2B Finish Sheet, High Inconel Alloy 625 No.1 Mirror Finish Sheets, Inconel UNS N07718 CR Sheets, Alloy N06601 Hot Rolled Sheets, Inconel Alloy 2.4856 Sheets Supplier, Alloy 2.4851, 2.4816 Sheets Exporter.
Alloy 600, 601, 625 Plates
Inconel 600, 601, 625 Plates
Inconel 600 Cold Rolled Plates, Alloy 601 2B Finish Plate, High Inconel Alloy 625 No.1 Mirror Finish Plates, Inconel UNS N07718 CR Plates, Alloy N06601 Hot Rolled Plates, Inconel Alloy 2.4856 Plates Supplier, Alloy 2.4851, 2.4816 Plates Exporter.
Alloy 600, 601, 625 Coils
Inconel 600, 601, 625 Coils
Inconel 600 Cold Rolled Coils, Alloy 601 2B Finish Coil, High Inconel Alloy 625 No.1 Mirror Finish Coils, Inconel UNS N07718 CR Coils, Alloy N06601 Hot Rolled Coils, Inconel Alloy 2.4856 Coils Supplier, Alloy 2.4851, 2.4816 Coils Exporter.
Equivalent Grades of Inconel 600 / 601 / 625 Sheets, Plates and Coils
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Chemical Composition of Inconel 600, 601, 625 Sheets and Plates, Coils
Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | - | 5.0 max | 58.0 min | 20.0 - 23.0 |
Alloy 600 / 601 / 625 Sheets, Plate, Coils Mechanical Properties
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Inconel Alloy 600, 601, 625 Sheets, Plates, Coils Make
ThyssenKrupp Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
Baosteel Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
Aperam Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
Posco Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
Outokumpu Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
ArcelorMittal Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
Nippon Steel & Sumitomo Metal Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
JFE Steel Corporation Make Inconel 600 / 601 / 625 Sheets, Plates, Coils
