Alloy 20 Steel Fasteners Supplier, Exporter and Manufacturer.

Alloy 20 Steel Fasteners, Alloy 20 Steel Industrial Fasteners, Alloy 20 Steel Bolts, Alloy 20 Steel Washers, Alloy 20 Steel Anchor Fasteners, ASTM A563 Alloy 20 Steel Fasteners, Alloy 20 Steel Nuts, Alloy 20 Steel Fasteners Manufacturer in Mumbai India.

20%
VISION

50%
MISSION

98%
QUALITY

Alloy 20 Steel F1 Heavy Hex Bolts, Cr-Mo F5 U Bolts, Alloy 20 Steel Stud Bolts, ASME SA563 Alloy 20 Steel Fasteners Exporter, Alloy 20 Steel Fastener, High Alloy 20 Steel Spring Washer, Alloy 20 Steel Coupling Nuts, Alloy 20 Steel Fasteners Supplier in Mumbai India.

Stanley Alloy has a long history of providing high-quality Alloy 20 fasteners and is renowned as a top-rated company for generating these high-quality fasteners.

We only work utilizing items that satisfy global standards and norms, and we offer a wide range of specifications to our prestigious clients around the world.

Alloy 20 Fasteners is an austenitic alloy built to survive acidic environments, notably sulfuric and acetic acids. The maximum temperature range for Alloy 20 is 1000 degrees Celsius. Cold and hot workings, as well as traditional or old processes, can be used to make Alloy 20. Hot forging necessitates a temperature of up to 2250°F, however lowering the temperature to 1800°F prior to forging can cause problems. As a result, it is critical to examine the complete control system in order to achieve better results. Following hot workings, the temperature should be between 1725 and 1850°F for roughly 30-35 minutes per inch, followed by water quenching.When compared to 304 and 316L stainless steels, Alloy 20 has better crevice and pitting resistance. Alloy 20 is also designed to deal with chloride ions and stress - corrosion, both of which are common in 316L steels. The other common trade name that Alloy 20 has Incoloy 20, Carpenter 20 alloy and 20CB-3.

Alloy 20 Fasteners is widely used in chemical processing, petrochemical industries, paper and pulp industries, oil and gas industries, refinery industries, heat exchangers, and other applications because of its great usability.

Specification of Alloy 20 Steel Fasteners

Specifications: ASTM A563 / ASME SA563

Standard: DIN, ASTM, BS and all International Standards

Length: 3 mm to 200 mm

Size: M3 - M56 | 3/6" to 2" | Custom Sizes

Grade: F1 / F5 / F9 / F12 / F91

Type: Nuts, Bolts, Screws, Sockets, Studs, Screw, Hex Set Screw, Socket Screw, Cap Screw, Pan Head Screw, Machine Screw, Socket Head Cap Screw, Allen Cap screw, Wing Screw, Washers, Spring Washers, Studs, Anchors, Marine Anchors, Nut, Hexagon Nut, Hex Nut, Hex Coupling Nut, Hex Domed Cap Nuts, Square Nut, Stud Bolts, Hex Head Bolts, Socket Hexagon Head Screw Anchor Bolt, U- Bolts, J Bolts, Mushroom Head Square Neck Bolts, T-Head Bolts, Wing Screw, Eye Bolt, Foundation Bolts, Structural Bolts etc.

Available Types of Alloy 20 Steel Fasteners

Bolts

ASTM A563 Alloy 20 Steel Bolts, A563 Alloy 20 Steel Hex Bolts, Alloy 20 Steel U Bolts, Alloy 20 Steel J Bolt, Alloy 20 Steel Bolts Supplier, Alloy 20 Steel Bolts Exporter.

Nuts

ASTM A563 Alloy 20 Steel Nuts, A563 Alloy 20 Steel Heavy Hex Nuts, Alloy 20 Steel Lock Nut, Alloy 20 Steel Square Nuts, Alloy 20 Steel Nuts Supplier, Alloy 20 Steel Nuts Exporter.

Washers

ASTM A563 Alloy 20 Steel Washers, A563 Alloy 20 Steel Plain Washer, Alloy 20 Steel Tooth Washers, Alloy 20 Steel Tab Washer, Alloy 20 Steel Washers Supplier, Alloy 20 Steel Washers Exporter.

Screws

ASTM A563 Alloy 20 Steel Screws, A563 Alloy 20 Steel Hex Screws, Alloy 20 Steel Coach Screws, Alloy 20 Steel Fully Threaded Screws, Alloy 20 Steel Screws Supplier, Alloy 20 Steel Screws Exporter.

Anchor Fasteners

ASTM A563 Alloy 20 Steel Anchor Fasteners, A563 Alloy 20 Steel Sleeve Type Anchor Bolts, Alloy 20 Steel Wedge Type Anchor Bolts, Alloy 20 Steel Anchor Fasteners Supplier, Alloy 20 Steel Anchor Fasteners Exporter.

Threaded Rods

ASTM A563 Alloy 20 Steel Threaded Rods, A563 Alloy 20 Steel Metric Threaded Rod, Alloy 20 Steel Partially Threaded Rod, Alloy 20 Steel Threaded Rods Supplier, Alloy 20 Steel Threaded Rods Exporter.

Equivalent Grades of Alloy 20 Fasteners

STANDARD	WERKSTOFF NR.	UNS	EN	AFNOR
Alloy 20	2.4660	N08020	NiCr20CuMo	Z2NCUD31-20AZ

Chemical Composition of Alloy 20 Fasteners

Grade	C	Mn	Si	S	Cu	Ni	Cr	Fe	Mo
Alloy 20	0.02 max	1.0-2.0 max	0.7 max	0.005 max	3.00 – 4.00	32.00 – 38.00	19.00 – 21.00	Bal.	2.00 – 3.00

Mechanical properties of Alloy 20 Fasteners

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Alloy 20	8.1 g/cm3	1443 °C (2430 °F)	Psi -80,000, MPa -551	Psi - 35,000, MPa - 241	30 %
